定扭矩電動扳手的使用不可小覷,從使用方面來看它們的大致操作都是相同的,并且其使用過程在操作步驟方面都可以分為調節扭矩和緊固螺栓兩個主要步驟。具體要懂以下內容。
The use of fixed-torque electric wrenches can not be underestimated. Their general operation is the same in terms of use, and their use process can be divided into two main steps: adjusting the torque and tightening the bolts. Specific to understand the following content.
調節扭矩:定扭矩電動扳手扭矩的調節是需要根據其緊固對象來確定的,按照緊固對象的大小來將扭矩進行調節,并設定固定值的扭矩。在這個操作過程中,需要注意的是扭矩的調節到設定,應定要在聽到報訊聲之后才算完成,并且要在設定好扭矩之后保持鎖定環靠近自己的虎口位置,于具體的扭矩?cái)?shù)值則以扳手能夠鎖緊螺母為宜。
Adjusting Torque: The regulation of the torque of the fixed-torque electric wrench needs to be determined according to its fastening object. The torque is adjusted according to the size of the fastening object, and the fixed value of the torque is set. In this operation, it should be noted that the adjustment of the torque to the setting should be completed only after hearing the news, and the locking ring should be kept close to its tiger mouth position after setting the torque. As for the specific torque value, it is advisable that the wrench can lock the nut.
緊固螺栓:在設定好扭矩之后就可以開始緊固螺栓了,要注意在進行緊固的時候注意力度。其中操作的力度要以適中為宜,以此來避免力度過小造成的緊固效果和效率不良,以及力度過大可能會造成的螺栓損壞問題。并且在緊固螺栓的過程中,如果感覺到扭矩過松,依然可以停下緊固操作,在調節和設定好扭矩之后再繼續進行和完成螺栓的緊固工作。
Tightening bolt: After setting the torque, the bolt can be tightened. Attention should be paid to the strength when tightening. The operation should be moderate in order to avoid the poor tightening effect and efficiency caused by too small force, and the bolt damage caused by too large force. In the process of tightening the bolt, if the torque is too loose, the tightening operation can still be stopped. After adjusting and setting the torque, the tightening work of the bolt can be continued and completed.
定扭矩電動扳手的主要功能是緊固,通過這兩個步驟的操作就能夠使用非常優勢地完成相應的工作。
The main function of the fixed torque electric wrench is tightening. Through the operation of these two steps, the corresponding work can be accomplished with great advantage.
定扭矩電動扳手使用方法：
Use method of fixed torque electric wrench:
1、根據工作所需扭矩值要求，確定預置扭矩值。
1. Determine the preset torque value according to the required torque value.
2、預置扭矩值時，將六角調節鑰匙插入扳手尾端，然后旋轉，調節標尺刻線所需扭矩值。調節好后，將鑰匙拉出。
2. When presetting the torque value, insert the hexagonal adjusting key into the end of the wrench, then rotate and adjust the ruler's marking to the required torque value. After adjusting, pull out the key.
3、在扳手方榫上裝上相應套筒，并套住緊固件，再在手柄上平穩地施加扭矩額定扭矩。當擰緊到發出信號“嗒”的一聲（已達到預置扭矩值）止，一次作業完畢。
3. Install the corresponding sleeve on the square tenon of the wrench, and cover the fastener, then apply the torque to the rated torque smoothly on the handle. When tightened to the signal "click" (reached the preset torque value), one operation is completed.
